Top Hammer Drilling Rig Mining Blasting Drill Machine Portable Small Drilling Rig for Sale

1set/bộ mỗi tháng
MOQ
negotiable
giá bán
Top Hammer Drilling Rig Mining Blasting Drill Machine Portable Small Drilling Rig for Sale
Đặc trưng Bộ sưu tập Mô tả sản phẩm Yêu cầu báo giá
Đặc trưng
Thông số kỹ thuật
Tên sản phẩm: Máy khoan búa hàng đầu DTH
tên: Đồ khoan khai thác mỏ,Đồ khoan thủy lực
Loại điện: Diesel
Sức mạnh (W): 60kw tại 2200 vòng/phút
Đường kính khoan: 40-100mm
Độ sâu khoan: 20m
Tiêu thụ không khí: 1,8-5 m3/phút
Tốc độ đi bộ: 2,5km/h-3km/h
Cách sử dụng: Khoan đá, Khoan lỗ, Khoan đá cứng
Áp lực: 5 thanh
khả năng lớp: 30 °
Ứng dụng: Khoan đá, quặng, mỏ
Loại máy: Thiết bị khoan
Kiểu: Giàn khoan quay
Kích thước (L * W * H): 3800*1910*2200mm
Cân nặng: 5000kg
Tính năng: Hiệu quả khoan cao, kiểm soát thủy lực, giá cả cạnh tranh
Làm nổi bật:

portable top hammer drilling rig

,

small mining blasting drill machine

,

DTH drilling rig with warranty

Thông tin cơ bản
Nguồn gốc: Chiết Giang, Trung Quốc
Hàng hiệu: SANROCK
Chứng nhận: CE ISO 9001:2015
Số mô hình: T55
Thanh toán
chi tiết đóng gói: Gói khỏa thân cho máy móc, gói hộp gỗ cho phụ tùng hoặc nhu cầu của khách hàng.
Thời gian giao hàng: 15-25 ngày
Điều khoản thanh toán: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Khả năng cung cấp: 5000set/bộ mỗi tháng
Mô tả sản phẩm

Top Hammer Drilling Rig Mining Blasting Drill Machine Portable Small Drilling Rig for Sale 0

Top hammer drill rigs are a reliable and efficient choice for drilling operations,

offering a combination of high efficiency, adaptability, accuracy, durability,

and versatility that is hard to match in the industry.

These drill rigs offer excellent adaptability. They can be used in a wide rangeof geological conditions, from relatively soft rocks to extremely hard and abrasive ones.

The ability to adjust the drilling parameters, such as the impact force, rotation speed,

and feed rate, according to the specific characteristics of the rock, ensures optimal

performance regardless of the challenging environment.

Top Hammer Drilling Rig Mining Blasting Drill Machine Portable Small Drilling Rig for Sale 1

Top Hammer Drilling Rig Mining Blasting Drill Machine Portable Small Drilling Rig for Sale 2Top Hammer Drilling Rig Mining Blasting Drill Machine Portable Small Drilling Rig for Sale 3



Feature:

These drill rigs offer excellent adaptability. They can be used in a wide range

of geological conditions, from relatively soft rocks to extremely hard and abrasive

ones. The ability to adjust the drilling parameters, such as the impact force, rotationspeed, and feed rate, according to the specific characteristics of the rock, ensures

optimal performance regardless of the challenging environment.

With an adjustable track tensioning system and reinforced undercarriage, the rig maintains

exceptional stability while traversing inclines up to 30° and operating on gradients as steep as 15°.

Top Hammer Drilling Rig Mining Blasting Drill Machine Portable Small Drilling Rig for Sale 4Top Hammer Drilling Rig Mining Blasting Drill Machine Portable Small Drilling Rig for Sale 5Top Hammer Drilling Rig Mining Blasting Drill Machine Portable Small Drilling Rig for Sale 6



Products Description

Product name
Drilling Rig
Power Parameters
Engine Model
4BTA3.9-C80-II
Rated Power
60kw at 2200rpm
Moving Parameters
Movement Speed
2.5km/h,3km/h
Climbing ability
30°
Machine parameters
Dimension
3800*1910*2200mm
Weight
5000kg
Clearance
260mm
Compressor Parameter
Air consumption
1.8-5 m3/min
Pressure
5 bar
Drilling parameters

Diameters
40-100mm
Depth
20m
Rock Drill
Weight
120kg
Length(without shank adapter)
655mm
width
299mm
height
204mm
Impact power
12.5kw
Max pressure
160Mpa
Flow rate
80L/min
Impact frequency
63HZ
Max Impact energy
200J


Top Hammer Drilling Rig Mining Blasting Drill Machine Portable Small Drilling Rig for Sale 7

Top Hammer Drilling Rig Mining Blasting Drill Machine Portable Small Drilling Rig for Sale 8

Top Hammer Drilling Rig Mining Blasting Drill Machine Portable Small Drilling Rig for Sale 9

Top Hammer Drilling Rig Mining Blasting Drill Machine Portable Small Drilling Rig for Sale 10

Top Hammer Drilling Rig Mining Blasting Drill Machine Portable Small Drilling Rig for Sale 11

Top Hammer Drilling Rig Mining Blasting Drill Machine Portable Small Drilling Rig for Sale 12

Top Hammer Drilling Rig Mining Blasting Drill Machine Portable Small Drilling Rig for Sale 13Top Hammer Drilling Rig Mining Blasting Drill Machine Portable Small Drilling Rig for Sale 14





Company Profile

Top Hammer Drilling Rig Mining Blasting Drill Machine Portable Small Drilling Rig for Sale 15

Top Hammer Drilling Rig Mining Blasting Drill Machine Portable Small Drilling Rig for Sale 16

Top Hammer Drilling Rig Mining Blasting Drill Machine Portable Small Drilling Rig for Sale 17

1.What can you buy from us?

DTH drilling rig,Integrated DTH DTH drilling rig ,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,Underground jumbo drill rig ,DTH hammer,screw air compressor,screw air compressor,piston air compressor,pneumatic rock drill ,drill rod,drill bit,PDC drill bit,top hammer drill bit,tricone bit ,spare parts.



2.How can I make payment?

A:You can pay by credit card, TT, Western Union, LC etc.



3.How is the shipment? How long dose it take?

A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT. You can also appoint shipping method you like before we ship.



4.How is your quality control?
A: We have our own experienced QC. There will be strict inspection and testing for every order before shipping out.
