Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor

1 bộ/ bộ
MOQ
negotiable
giá bán
Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor
Đặc trưng Bộ sưu tập Mô tả sản phẩm Yêu cầu báo giá
Đặc trưng
Thông số kỹ thuật
Tên sản phẩm: Máy Nén Khí Trục Vít,Máy Nén Khí
tên: Máy nén khí trục vít Diesel
Sức mạnh: 410kw
Nguồn năng lượng: Dầu diesel
Áp lực: 21-25bar/21-34bar
Tiêu thụ không khí: 31-29m2/phút 36,5-32m2/phút
Tốc độ: 1600/1400rpm 1830/1400rpm
Công suất bể nhiên liệu: 700L
Công suất dầu bôi trơn: 120L
Phương pháp làm mát: Cả làm mát bằng không khí / nước đều có sẵn
Ứng dụng: Dự án khai thác mỏ, than, quặng
Loại: Đinh ốc
Thành phần cốt lõi: PLC, Bình chịu áp lực, Động cơ, Động cơ, Bơm, Vòng bi
Cấu hình: Đứng im
Kích thước ((L*W*H): 4100*1800*2050mm
Trọng lượng: 5600kg
Làm nổi bật:

Mining Screw Air Compressor 34bar

,

Mobile Screw Air Compressor

,

Screw Air Compressor Machine 25bar

Thông tin cơ bản
Nguồn gốc: ZheJiang, Trung Quốc
Hàng hiệu: SANROCK
Chứng nhận: CE ISO 9001:2015
Số mô hình: tùy chỉnh
Thanh toán
chi tiết đóng gói: Gói khỏa thân cho máy móc, Gói hộp gỗ cho phụ tùng thay thế, Hoặc nhu cầu của khách hàng.
Thời gian giao hàng: 18-25 ngày làm việc
Điều khoản thanh toán: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Khả năng cung cấp: 5000Bộ / Bộ mỗi tháng
Mô tả sản phẩm

Stationary Screw Air Compressor
A stationary screw air compressor is a robust, high-efficiency industrial air compression system designed for continuous operation in demanding environments. Utilizing dual rotary screw rotors, it delivers smooth, pulsation-free compressed air with energy efficiency and low maintenance requirements. The fixed installation ensures stability and noise reduction. Equipped with smart control systems, automatic drainage, and low-maintenance design, these compressors provide reliable performance in diverse environments.

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 0Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 1



Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 2

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 3

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 4Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 5



Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 6

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 7

Products Description

Brand Name:Sanrock
Product name: screw air compressor
Compressor
Pressure (bar)
21-25 21-34
Air consumption (m²/min)
31-29 36.5-32
Lubricating oil capacity(L)
120
Dual transformation
Dual
Engine
brand
Cummins
Mode
QSZ 13-C550
Power (kw)
410
Max working/idle speed (rpm
1600/1400 1830/1400
Cylinder No
6
Total displacement(L)
13
Emission standard
Stage Ⅲ
Fuel tank capacity (L)
700
Unit
xhaust port specifications *Quant
G2*1&G3/4*1
Wheel specifications *Quantity
Skid mounted
Noise[Db(A)]
85±3
Dimension (mm
4100x1800x2050
Weight (kg)
5600


Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 8

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 7
Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 10

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 11

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 12Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 13

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 14Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 15

Company Profile

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 16

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 17

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 18

1.What can you buy from us?
DTH drilling rig,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,underground jumbo drill rig ,hydraulic scaling rig,DTH hammer,drill rod,screw air compressor,water well drilling rig,truck mounted water well drilling rig,reverse circulation drilling rig,environmental drilling rig,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,tricone bit ,spare parts.



2.How can I make payment?
A:You can pay by credit card, TT, Western Union, LC etc.



3. How is the shipment? How long dose it take?
A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT.You can also appoint shipping method you like before we ship.



4.How is your quality control?
A: We have our own experienced QC.There will be strict inspection and testing for every order before shipping out.
