The disc-type drill frame is an auxiliary device designed and manufactured to adapt to the use of the SR90 type rail-guided independent hydraulic rotary rock drill in small-section mining roadways. It is powered by compressed air to achieve the pushing and positioning functions of the rock drill during drilling.
Compressed air passes through the main intake valve, oil mist lubricator, various control valves and reaches each moving part to achieve the cyclic operation of the rock drilling process.
This drill frame has a simple structure, is easy to disassemble and transport, operates safely and reliably, and is highly efficient. The entire drilling frame is composed of three components: the drilling frame connection part, the propeller connection part and the operation platform connection part. The drilling frame connection part mainly includes three parts: the air top, the disc and the bottom skid. The propeller joint is composed of four components: the brazing device, the guide rail, the slide seat and the propulsion motor. The console assembly includes main components such as the control valve and the oil mist lubricator.
